Mitsubishi FX1N Series Programming Manual

FX Series Programmable Controlers Applied Instructions 5
5-200
5.16.1.1.5 EXTR K11 - Control operations (PLC to Inverter)
Details of S3
Note:
The shaded areas are re-written in the internal processing when EXTR K13 is executed.
16 Bit Operation
ü
32 Bit Operation
û
Pulse - P
û
Parameter Device type Parameter range
S1 K/H K11: function No. to control inverter operations
S2 KH, D Inverter station number (0 to 31)
S3 KH, D Inverter instructuion code (varies with model)
S4 KH D, KnX, KnY, KnM, KnS Value to be written to inverter
S3 Control contents A500 E500 S500 Data digits Comms format
HFB Operation mode
üüü 4AðC|D
HF3 Special monitor selection No.
ü 2A’ðC|D
HFA Operation command
üüü 2A’ðC|D
HEE Set frequency read (EEPROM)
üüü 4AðC|D
HED Set frequency read (RAM)
üüü 4AðC|D
HFD Inverter reset
üüü 4 A (no response)
HF4 Alarm definition batch clear
üü4AðC|D
HFC All parameter clear
üüü 4AðC|D
H80~HFD Parameter write ü ü ü 4 AðC|D
HFC User clear
ü 4AðC|D
HFF Link parameter extension setting ü ü ü 2 A’ðC|D
HEC
Second parameter changing
(code FF=1)
ü ü ü 2 A’ðC|D
EXTR K11 K4 HFA K02
S1 S2 S3 S4
