Mitsubishi FX1N Series Programming Manual

FX Series Programmable Controlers Applied Instructions 5
5-205
No. Reading and Writing to parameters which require a second parameter
For parameters that require the setting of a second parameter. If a value of ‘+0’, ‘+1000’ or
‘+2000’ issettoaparameterNo.intheinvertermanual,thesecondparameterwillbe
automatically re-written before a general parameter read/write.
No. Item
Instruction
code
Description
Number of
data digits
13
Second
parameter
changing
(code
FF=1)
Read H6C
When setting the programmed operation
(data code H3D to H5A, HBD to HDA)
parameter
H000: time
H001: time
H002: rotation direction
When setting the bias/gain (data code H5E to H6A, HDE to
HED) parameter
H000: Offset/Gain
H001: Analog
H002: Analog value of terminal
2digits
Write HEC
Classification Offset for parameter number
a)
H00: Operation frequency +0
H01: Time +1000
H02: Rotation direction +2000
b)
H00: Offset / Gain +0
H01: Analog +1000
H02: Analog value of terminal +2000

Mitsubishi FX1N Series Specifications

General

Programming Language	Ladder Logic
Output Type	Relay, Transistor
Operating Temperature	0 to 55°C
Power Supply	100-240V AC or 24V DC
Program Capacity	8K steps
Communication Ports	RS-422
Data Memory	8000 words
High-speed Counters	Up to 6 channels
Expansion Modules	Available
Pulse Output	2 points
