FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
8 Terminal Block Specifications and External Wiring
8.1 Overview
1
Outline
2
External Dimensions
3
Generic Specifications
4
Power Supply Specifications
5
Input Specifications
6
Output Specifications
7
Examples of Wiring for Various Uses
8
Terminal Block
9
CC-Link/LT Master FX
3UC
(LT only)
10
Display module FX
3UC
(LT only)
*1. The table below shows the drive power supply for each connection destination.
*2. The applications shown below are not supported.
*3. The applications shown below are not supported.
*4. The table below shows the drive power supply for each connection destination.
Connection destination Power Supply Voltage Current Consumption
Input connector
FX
3UC-MT/D, FX3UC-32MT-LT, FX2NC-EX Not required
FX
3UC-MT/DSS, FX2NC-EX-DS, FX2N-16EX-C 24V DC 112mA
Output connector
FX
3UC-MT/D, FX3UC-MT/DSS, FX3UC-32MT-LT,
FX
2NC-EYT, FX2NC-EYT-DSS, FX2N-16EYT-C
Power supply suitable to connected load is
required.
Unsupported Applications
High-speed
processing
High-speed counter, input interruption, pulse catch, speed detection (SPD) instruction
Time division
input
Input matrix (MTR) instruction, hexadecimal input (HKY) instruction, digital switch (DSW)
instruction, arrow switch (ARWS) instruction
Other
Refresh and filter adjust (REFF) instruction, ten key input (TKY) instruction, absolute current
value read (ABS) instruction
Unsupported Applications
Pulse output
Pulse Y output (PLSY) instruction, acceleration/deceleration setup (PLSR) instruction, pulse
width modulation (PWM) instruction, DOG search zero return (DSZR) instruction, interruption
positioning (DVIT) instruction, batch data positioning mode (TBL) instruction, absolute current
value read (ABS) instruction, zero return (ZRN) instruction, variable speed pulse output (PLSV)
instruction, drive to increment (DRVI) instruction, drive to absolute (DRVA) instruction
Time division
input
Input matrix (MTR) instruction, hexadecimal input (HKY) instruction, digital switch (DSW)
instruction, arrow switch (ARWS) instruction
Time division
output
Seven segment with latch (SEGL) instruction, print (ASCII Code) (PR) instruction
Connection destination Power Supply Voltage Current Consumption
FX
3UC-MT/D, FX3UC-32MT-LT, FX2NC-EX 24V DC 48mA
FX
2N-16EX-C 24V DC 160mA
