FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
1 Outline
1.4 List of Products
1
Outline
2
External Dimensions
3
Generic Specifications
4
Power Supply Specifications
5
Input Specifications
6
Output Specifications
7
Examples of Wiring for Various Uses
8
Terminal Block
9
CC-Link/LT Master FX
3UC
(LT only)
10
Display module FX
3UC
(LT only)
2. High-speed counter
When connected to the special function blocks in the following table, the FX2NC-CNV-IF or FX3UC-1PS-
5V is required.
3. Pulse output and positioning
When connected to the special function units/blocks in the following table, the FX2NC-CNV-IF or FX3UC-
1PS-5V is required.
*1. Up to 3 units can be connected to one system. Connect them to the end of the system. For details,
refer to the FX2N-1RM(-E)-SET Handy Manual.
Model name Description
Number
of input/
output
points
5V DC current
consumption
(mA)
FX
2N-1HC 1-ch high-speed counter 8 90
Model name Description
Number
of input/
output
points
5V DC current
consumption
(mA)
FX
2N-1PG
Pulse output for independent 1-axis control [100 kHz
open collector output]
855
FX
2N-1PG-E
Pulse output for independent 1-axis control [100 kHz
open collector output]
855
FX
2N-10PG
Pulse output for independent 1-axis control
[1 MHz differential line driver output]
8120
FX
3U-20SSC-H
Simultaneous 2-axis (independent 2-axis) control
[Applicable to SSCNET III]
8100
FX
2N-10GM
Pulse output for independent 1-axis control
[200 kHz open collector output]
8-
FX
2N-20GM
Pulse output for simultaneous 2-axis (independent
2-axis) control [200 kHz open collector output]
8-
FX
2N-1RM-SET
*1
1-axis programmable cam switch
8
*1
-
FX2N-1RM-E-SET
*1
1-axis programmable cam switch
8
*1
-
Number of
connected units
Number of input/output
points occupied
Count of number of connected special
function units/blocks
1 unit
8 points 12 units
3 units
