FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
1 Outline
1.4 List of Products
4. Data link and communication functions
When connected to the special function blocks in the following table, the FX2NC-CNV-IF or FX3UC-1PS-
5V is required.
*1. Either the FX
2N-16CCL-M or the FX2N-32ASI-M can be connected in one system.
Only one FX
2N-32ASI-M unit can be connected in a system. Two or more FX2N-16CCL-M units
can be connected in one system, but remote I/O stations cannot be connected to the second and
later master stations.
*2. The number of input/output occupied points in the FX
2N-16CCL-M is obtained using the following
formula
Number of input/output occupied points = Number of remote I/O stations × 32 points + 8 points
*3. The number of input/output occupied points in the FX
2N-64CL-M is obtained using the following
formula
Number of input/output occupied points = Total number of input/output points in remote I/O
stations + 8 points
*4. The number of input/output occupied points in the FX
2N-32ASI-M is obtained using the following
formula
Number of input/output points =
Main unit (Ver.2.20 or later) Number of active slaves × 8 points + 8 points
Main unit (Earlier than Ver.2.20) Number of active slaves × 4 points + 8 points
*5. The number of points varies according to the products connected to the network.
For details, refer to the FX
2N-16LNK-M Manual.
Model name Description
Number
of input/
output
points
5V DC current
consumption
(mA)
FX
2N-232IF 1-ch RS-232C no-protocol communication 8 40
FX
2N-16CCL-M*
1
Master for CC-Link
Connectable stations:
Remote I/O station: 7 stations
Remote device station: 8 stations
*2 -
FX
2N-32CCL
Remote device station for CC-Link
[1 to 4 stations occupied]
8 130
FX
2N-64CL-M Master for CC-Link/LT *3 190
FX
2N-32ASI-M*
1
Master for AS-i system *4 150
FX
2N-16LNK-M Master for MELSEC I/O Link *5 200
