3. SPECIFICATIONS
3.1 General Specifications
*1 : The wet bulb temperature is 39 or less.
*2 : Do not use or store the GOT under pressures higher than the atmospheric pressure of altitude 0m (0ft.). Failure
to observe this instruction may cause a malfunction.
*3 : This indicates the section of the power supply to which the equipment is assumed to be connected between the
public electrical power distribution network and the machinery within the premises.
Category II applies to equipment for which electrical power is supplied from fixed facilities.
The surge voltage withstand level for up to the raged voltage of 300 V is 2500 V.
*4 : This index indicates the degree to which conductive pollution is generated in the environment where the
equipment is used.
In pollution degree 2, only non-conductive pollution occurs but temporary conductivity may be produced due to
condensation.
Item Specifications
Operating
ambient
temperature
Display section
0 to 50
Other than
display section
0 to 55 (when horizontally installed), 0 to 50 (when vertically installed)
Storage ambient temperature
-20 to 60
Operating ambient humidity
*1
10 to 90% RH, non-condensing
Storage ambient humidity
*1
10 to 90% RH, non-condensing
Vibrationresistance
Conforms to
JIS B3502
and
IEC61131-2
Frequency Acceleration
Half-
amplitude
Sweep Count
Under
intermittent
vibration
5 to 9Hz - 3.5mm
10 times each
in X, Y and Z
directions
9 to 150Hz
9.8m/s
2
-
Under
continuous
vibration
5 to 9Hz - 1.75mm
9 to 150Hz
4.9m/s
2
-
Shock resistance
Conforms to JIS B3502, IEC 61131-2 (147 m/s
2
, 11 ms, Sine half-wave pulse, 3 times
each in the X, Y, and Z directions)
Operating atmosphere
Must be free of lamp black, corrosive gas, flammable gas, or excessive amount of
electroconductive dust particles.
Operating altitude
*2
2000 m (6562 ft) max.
Installation location Inside control panel
Overvoltage category
*3
II or less
Pollution degree
*4
2 or less
Cooling method Self-cooling
WWW.NNC.IR

Mitsubishi GOT1000 Specifications

General

Series	GOT1000
Power Supply	24 VDC
Type	HMI (Human Machine Interface)
Processor	RISC
Communication Interfaces	RS-232, USB
Storage Temperature	-20 to 60°C
Display Type	TFT LCD
Backlight Life	50, 000 hours
Operating Temperature	0 to 50 °C
