Mitsubishi GOT1000 User Manual

6 - 2
6.1 Control Panel Inside Dimensions for Mounting GOT
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
PART NAME
5
EMC DIRECTIVE
6
INSTALLATION
7
WIRING
8
OPTION
6.1 Control Panel Inside Dimensions for Mounting
GOT
Mount the GOT onto the control panel while considering the following control panel inside dimensions.
Horizontal format
Vertical format
(If the vertical format is selected, the dimension, which is rotated 90 degrees clockwise looking from the
display section side, is required.)
Applicable cable
Some cables may need to be longer than the specified dimensions when connecting
to the GOT.
Therefore, consider the connector dimensions and bending radius of the cable as
well for installation.
RS-232
(FG)
INPUT
24VDC
+
-
RS-422
CSB
SDA
SDB
RDA
RDB
SG
RSA
RSB
CSA
Unit: mm(inch)
84(3.3")
65(2.55")
76(2.99")
104(4.09")
76(2.99")
10
(0.39")
10
(0.39")
10
(0.39")
10
(0.39")
3(0.11")
5
(0.19")
9.5
(0.37")
4
(0.15")
23(0.9")
25(0.98") to 28(1.1")
RS-232 cable
for connecting
personal computer
80(3.14") or more
Mounting
fixtures
RS-232
(FG)
INPUT 24VDC
+ -
RS-422
CSB SDA SDB RDA RDB
SG
RSA RSB CSA
Unit: mm(inch)
84(3.3")
65(2.55")
76(2.99")
104(4.09")
76(2.99")
10
(0.39")
10
(0.39")
10
(0.39")
10
(0.39")
3(0.11")
5
(0.19")
9.5
(0.37")
4
(0.15")
23(0.9")
25(0.98") to 28(1.1")
RS-232 cable
for connecting
personal computer
80(3.14") or more
Mounting
fixtures
WWW.NNC.IR

Mitsubishi GOT1000 Specifications

General

Series	GOT1000
Power Supply	24 VDC
Type	HMI (Human Machine Interface)
Processor	RISC
Communication Interfaces	RS-232, USB
Storage Temperature	-20 to 60°C
Display Type	TFT LCD
Backlight Life	50, 000 hours
Operating Temperature	0 to 50 °C
