9 - 1
9.1 Utility Function List
9. UTILITY FUNCTION
The utility functions allow the user to confirm the settings for communication interface, screen display,
operation methods, and clock data as well as OS information.
GT10 is factory-installed with the Standard monitor OS and BootOS.
(An installation of the Standard monitor OS or BootOS is not required to use the utility functions.)
9.1 Utility Function List
The items in the following list can be set/operated on the utility screens.
Item Functions overview
Language
Switches the display language for the utility functions (Japanese/English)
Standard I/F
Displays the detailed information about the communication method and communication driver
Data transfer
Displays the screen for transferring project data between the PC and GOT
(If any device other than the PC is allocated to the interface for communication with PC, the
GOT will not be able to communicate with the PC, except when the Data transfer window is
on the screen.)
Communication monitor
Displays the communication status of each communication port
Screen save
Time
Sets the screensaver activation time (from the last time the screen was touched)
Setting range: 0 to 60 min. (Screensaver is disabled when it is set to 0 minute.)
Default : 0 min.
Backlight
This setting is used to decide whether to turn the backlight on or off when the screensaver
comes on
Default : OFF
Contrast
Adjusts the contrast on the liquid crystal display (16 level adjustment, 0 to 15)
Default : 10
Buzzer volume
Changes the buzzer settings (OFF/SHORT/LONG)
Default : SHORT
Calibration
Calibrates the touch panel sensitivity
Time setting Sets the clock (clock data) on the PLC
Data
OS information
Displays the OS (Standard monitor OS, BootOS) and communication driver versions
Clear data
Clears the project data and resource data on the GOT
