Mitsubishi GOT1000 User Manual

11 - 7
11.2 Data Transfer
11.2.3 Data transfer display
9
UTILITY FUNCTION
10
LANGUAGE SETTING
11
COMMUNICATION INTERFACE SETTING
12
DISPLAY AND OPERATION SETTINGS
13
CLOCK SETTING
14
FILE DISPLAY
15
OS INSTALLATION
16
MAINTENANCE AND INSPECTION
11.2.3 Data transfer display
[Waiting] on the data transfer screen will change to [Transferring...] when project data are transferred from
GT Designer2.
At the completion of data transfer, the user-created screen will appear.
Transfer of project data
from GT Designer2
Completion of data transfe
r
User-created screen
WWW.NNC.IR

Mitsubishi GOT1000 Specifications

General

Series	GOT1000
Power Supply	24 VDC
Type	HMI (Human Machine Interface)
Processor	RISC
Communication Interfaces	RS-232, USB
Storage Temperature	-20 to 60°C
Display Type	TFT LCD
Backlight Life	50, 000 hours
Operating Temperature	0 to 50 °C
