188
(30)CH Logging enable/disable setting (Un\G1000 to Un\G1003)
Set whether the logging is enabled or disabled.
For details on the logging function, refer to the following.
• Logging function ( Page 98, Section 8.14)
(a) Enabling the setting
Turn OFF → ON → OFF Operating condition setting request (Y9) to enable the setting.
(b) Default value
All channels are set to Disable (1).
● Enabling the setting starts the logging.
● In the channel where the following conditions are set, an error occurs. Then, the error code is stored in Latest error code
(Un\G19), Error flag (XF) is turned to ON and logging cannot be performed.
• When a value other than the above setting values is set
• When Conversion speed setting (Un\G26) is set to 20µs (0) and CH Logging enable/disable setting (Un\G1000
to Un\G1003) is set to Enable (0)
• When Input signal error detection setting (Un\G47) is set to Enable (0) and CH Logging enable/disable setting
(Un\G1000 to Un\G1003) is set to Enable (0)
• When Input signal error detection extension setting (Un\G27) is set to other than Disable (0) and CH Logging
enable/disable setting (Un\G1000 to Un\G1003) is set to Enable (0)
Logging enable/disable setting Setting value
Enable 0
Disable 1
