190
(33)CH Logging data setting (Un\G1024 to Un\G1027)
When the logging function is used, set whether the logging data type is Digital output value or Scaling value
(digital operation value).
For details on the logging function, refer to the following.
• Logging function ( Page 98, Section 8.14)
(a) Enabling the setting
Turn OFF → ON → OFF Operating condition setting request (Y9) to enable the setting.
(b) Default value
All channels are set to Scaling value (digital operation value) (1).
● In the channel where a value other than the above setting values is set, an error occurs. Then, the error code is stored in
Latest error code (Un\G19), Error flag (XF) is turned to ON and the logging cannot be performed.
● When CH Logging enable/disable setting (Un\G1000 to Un\G1003) is set to Disable (1), the setting for CH Logging
data setting (Un\G1024 to Un\G1027) is ignored.
Target of logging Setting value
Digital output value 0
Scaling value (digital operation value) 1
To Next Page
