CHAPTER 8 FUNCTIONS
8
8.7 Input Signal Error Detection Function
Remark
The following table lists the lower limit value, offset value, or gain value for each range.
Analog input range Lower limit value Offset value Gain value
Voltage
0 to 10V 0V 10V
0 to 5V 0V 5V
1 to 5V 1V 5V
-10 to 10V -10V 0V 10V
1 to 5V (Extended mode) 1V 5V
User range setting
Analog input value when the
digital output value is -20000
Analog input value set as
a offset value by the user
Analog input value set as
a gain value by the user
Current
0 to 20mA 0mA 20mA
4 to 20mA 4mA 20mA
4 to 20mA
(Extended mode)
4mA 20mA
User range setting
Analog input value when the
digital output value is -20000
Analog input value set as
a offset value by the user
Analog input value set as
a gain value by the user
