Stitching data type and writing No.
[4]. Stitching data type and writing No.
(1) Stitching data type
1. A data
*This is data created with the PLK-A Series.
*"Block movement" and "stitch length modification" cannot be executed in the modification
mode.
*"Offset", "Multiple", "Back tacking" and "Zigzag" cannot be executed in the data conversion
mode. "Constant stitch length enlargement/reduction" also cannot be executed.
2. BA data
*This is data created with the PLK-B Series and E Series.
*This is created when "BA data" is selected in the input mode.
*"Block movement" and "stitch length modification" cannot be executed in the modification
mode.
*"Offset", " Multiple ", "Back tacking" and "Zigzag" cannot be executed in the data conversion
mode. "Constant stitch length enlargement/reduction" also cannot be executed.
*Use this for embroidery data and when there are many input points (1,500 points or more).
3. B data
*This is data created with the PLK-B Series and E Series.
*This is created when "B data" is selected in the input mode.
Memo Creating this with the B data is recommended unless there are special conditions.
(2) Writing No.
1. A data
*Write to No. 100 to 299.
(If written into No. 400 to 499, the data will be automatically converted into BA data.)
*Conversion into B data is not possible.
2. BA data
*Write to No. 400 to 499.
(If written into No. 100 to 299, the data will be automatically converted into A data.)
*Conversion into B data is not possible.
3. B data
**Write to No. 600 to 799.
(If written into No. 100 to 299, the data will be automatically converted into A data.)
(If written into No. 400 to 499, the data will be automatically converted into BA data.)
Memo The number of maximum data (In the best condition) which can be written is up to 255
patterns for internal memory and 224 patterns for floppy disk. The number of the data which
can be written as follows according to the content of the data changes.
[Standards number of maximum writing by content of the pattern data（internal
memory）]
For the A and the BA data ----- They are up to 255 pattern can be write in case of 1 data
below 370 stitch’s for 1 pattern. If below 8000 stitch’s for 1 pattern, it
is possible to write up to 11 patterns.
For the B data -------------------- They are up to 255 patterns can be write in case of 1 data
below 100 stitch’s/50 points. If below 8000 stitch’s / 1500 points for 1
pattern, it is possible to write up to 6 patterns.
(3) Stitching data type and writing No. correspondence table
Writing
No.
Data type
0
〜
99
100
〜199
200
〜299
300
〜
399
400
〜499
500
〜
599
600
〜699
700
〜799
800
〜
899
900
〜
999
1.A data
(Read)
- A data -
Conversion
into BA
data
- - - - -
2.BA data
(Read/create)
-
Conversion
into A data
- BA data - - - - -
3.B data
(Read/create)
-
Conversion
into A data
-
Conversion
into BA
data
- B data - -
Writing into the "-" area is not possible.
