Modification mode
(5) Confirming on the image screen
If the image display key is pressed in the input mode, modification mode or conversion
mode, the Image screen will open.
This Image screen can be used effectively when modifying (converting) data in the
modification (conversion mode), and the data can be modified (converted) easily.
An example of the Image screen in the modification mode is shown below.
The Image screen can be confirmed after the data modification (conversion) mode is entered,
regardless of before and after modifications made.
* When stitching start position is modified
: Closes the Image screen, and
opens the previous screen.
(Common for all Image
screens.)
: Indicates the home position.
(Common for all Image
screens.)
: Indicates the original stitching
start position.
: Indicates the modified stitching
start position. (Current position
moved to with the arrow keys.)
<Only the image section is shown in the following explanations.>
* Deleting stitches
: Indicates the home position.
(Common for all Image screens.)
: Indicates the stitch deletion start
position.
: Indicates the stitch deletion end
position.
* Modifying the stitch position and adding stitches
: Indicates the home position.
(Common for all Image screens.)
: Indicates the original stitch
position/stitch addition reference
position.
: Indicates the modified stitch
position/added stitch position. (Current
position moved to with the arrow keys.)
To Next Page
