Data conversion mode
[13]-13
5. Confirming the converted data
* After converting the data, press
to quit the conversion mode.
(When is pressed,
the conversions executed last will be
undone.)
[Memo 1] Circle scaling
B data (600-799) ... A circle will be created even if the X, Y enlargement ratio/contraction
ratio are set to different values.
BA(400-499), A data(100-299) ... An ellipse will be created if the X, Y enlargement
ratio/contraction ratio are set to different values.
[Memo 2] Expanded/reduces for zigzag sewing, multiple sewing, and offset sewing.
In case of B data (Pattern number 600-799), sewing in zigzag, multiple, and offset an under
mentioned set item is not influenced by the expansion/the reduction.
( The function as the offset is lost by the expansion/the reduction about the offset. )
*“Amount of stitch length” and “Width of shake” of zigzag sewing
*"Distance" of multiple sewing
*"Distance" of offset
( Do not use expansion/reduction but respectively to change these [13 ] - ( 8 ) zigzag sewing,
[ 13 ] - ( 13 ) multiple sewing, [13 ] - ( 12 ) offset sewing in the conversion mode if modify to
do.
Example ***** It is expanded like 3mm of B in the offset width, when data [A] of multiple
sewing of the 3mm width and expands 200% of X scale made by B data like the figure
below.
[A] [B]
[Memo 3] "Fixed stitch number/stitch length fixed" setting for expanded/reduces for zigzag sewing
In case of B data (Pattern number 600-799), "stitch number fixed/stitch length fixed" setting
of the expansion/the reduction is not influenced by zigzag sewing.
( Please reference to [ 13 ] - (8 ) Conversion mode of zigzag sewing or [ 12 ] - ( 15 ) block
correction to do. )
