Program mode list
[17] Program mode list
Changing to the program mode
When using the LCD panel, refer to the section " Operation panel section[16] Program mode ". When using the 7-segment operation
panel keys, refer to pages " Control unit section[8]-3 to [8] -4".
* For item (*1), there is no LCD panel program mode item. Change to each mode using the 7-segment operation panel keys. Depending
on the item, the other LCD panel functions can be operated. (For example, [O1L] in the "output signal" item can be operated from the
"input/output setting mode".)
Table explanation
[ type ]
[ symbol ] [ function name ] [mode]
Wiper
WIP Wiper ON/OFF 4(1)
W1 Wiper output (W) output start time B33
W2 Wiper output (W) output time B34
Slow start
S Slow start speed B43
SL Slow start setting B44
SLN Number of slow start stitches B45
Clamp
OST
Start/stop even if work holder is not
lowered
G40
RPT Repeat sewing setting G1
RP(1-8) Work holder 1-8 repeat sewing setting
G(2-
9)
WHY Work holder order of priority setting G10
FSR All cancel during step over operation G11
1PD 1-pedal specification setting G12
1T 1-pedal timer setting G13
(1-8)A Work holder 1-8 ON delay timer setting
G(14
-21)
(1-8)B
Work holder 1-8 OFF delay timer
setting
G(22
-29)
OFB Number of Work holder division setting G30
FN Number of rated Work holder setting G31
CF Work holder sequence setting G32
F21N
Valid Work holder number setting for
divided Work holder (OF1…OF4)
G33
F22N
Valid Work holder number setting for
divided Work holder (OF5…OF8)
G34
CF1
Work holder sequence setting for
divided Work holder (OF1…OF4)
G35
CF2
Work holder sequence setting for
divided Work holder (OF5…OF8)
G36
F4BN
Valid number setting of Work holder
blocks
G37
F4SN Number of block steps setting G38
AF2
Pneumatic type two stage work holder
selection
G39
Sewing area
ALC Sewing area limit cancel A1
XL [X axis left side] area limit setting X5
XR [X axis right side] area limit setting X6
YU
[Y axis back side] area limit
modification
X7
YD
[Y axis front side] area limit
modification
X8
Needle position
RU
Reverse run needle UP function after
thread trimming
B5
R8 RU reverse angle setting B6
U8 Needle UP position stop angle B7
D8 Needle DOWN position stop angle B8
Bobbin winding
W Bobbin winding speed B46
WSM Bobbin winding operation setting B47
WT Bobbin winding operation time B48
Home position
HPM Home position return method at HALT A10
HPC
Home position return prohibit at power
ON
A11
HPF
Automatic home position return
operation prohibition
A12
HPK Reset key setting A14
2HS
Temporary stop method at secondary
home position
A15
FHP Free home position usage method A16
CHS
Home position correct selection at
sewing data read
A17
SHX
[X axis] limit sensor home position
return
X9
SHY [Y axis] limit sensor home position return X10
HPS
Setting for presser foot state of home
return operation after power ON
A13
HALT
STF
Feed data stop state at HALT switch
operation
A2
STN
Needle stop state at HALT switch
operation
A3
STS
Various output hold at HALT switch
operation
A4
ST2 HALT switch two-press operation A5
STP
Power operation at HALT switch
operation
A7
STD
Work holder raise operation when
stopped with HALT code
A8
STL Double-drop prevention after HALT A9
Counter
CUP Increment (UP) counter function A21
CDN Decrement (DN) counter function A22
UCM
Increment (UP) counter setting value
clear method
A23
DCM
Decrement (DN) counter setting value
clear method
A24
PCM Counter clear method at power ON A25
CN Number of stitches count function A26
UCC
Increment (UP) counter count value
correction prohibit
A27
DCC
Decrement (DN) counter count value
correction prohibit
A28
USC
Sewing work with increment (UP)
counter
A29
DSC
Sewing work with decrement (DN)
counter
A30
Brakes
WBK Weak brake setting B1
BKM Weak brake function setting B2
BNR Weak brake noise setting B3
BKT Brake time setting B4
PW
Weak brake operation time during
presser bar lifting operation
X23
Presser foot
PD
Presser bar lifting timer 1 (lowering)
setting
B35
PU Presser bar lifting timer 2 (rising) setting B36
UW Presser bar lifting timer 3 (rising) setting B37
BPF
Setting of presser foot when baste is
sewn and the feed moves
B26
