Methods of creating stitching data
[9]-32
Memo (A) It is for the combination data of a curve input and multiple sew.
The data like the figure below (right) is made as shown in the figure below (left) when curves
which pass point 2, point 3, and point 4 after an feed from the home position to point 1 are
combined with multiple sewing and inputs.(Distance=10mm and 2 times of "Frequency")
The distance of the multiple data becomes "It is narrow" the data as shown in figure.
They are not like to make this partially narrow multiple data, to make a constant distance multiple
data as much as possible, please input 2' between 2 and 3 as shown in the figure below (left).
The multiple data as shown in the figure below (right) is made.
Memo (B) It is for the combination data of a curve input and multiple sew.
Thedatalikethefigurebelow(right)ismadeasshowninthefigurebelow(left)whencurves
whichpasspoint2,point3,andpoint4afteranfeedfromthehomepositiontopoint1are
combinedwithmultiplesewingandinputs.(Distance=8mmand4timesof"Frequency")
The data is made in the curve that the fourth curve is different as understood from
figure(fight).
The distance of the multiple data becomes "It is narrow" the data as shown in figure.
When the virtual input point which makes the multiple is requested by the operation, such a
situation like the figure below, the reason for it is to intersect in the multiple.
Moreover, such a situation changes variously depending on the condition of the input point etc. of
"Distance", "Frequency" of the multiple data, and the curve.
Please use a variety of trying.
