Methods of creating stitching data
Deflection width, feed amount and creation direction
Memo When the direction of making is made
"Center" , does not become a
zigzag pattern data if "Width of the
shake" is 0.1mm.
Please set "Width of the shake" to
0.2mm or more, or whether to do the
direction of making is other then
"Center".
Travel direction right side
Travel direction left side
Travel direction center
Feed amount
Deflection width
3. Setting the back tacking details
* After returning to the Input Method
Setting screen, press the back Tacking
Details
Setting key .
* The details are set on this screen.
(The details set here are, ,
overlap
mode , three overlap stitches.)
* After inputting the details, press
to set the data.
* The system will return to the input
method setting screen.
* Press to determine the set
values.
To Next Page
