Digital Logic Control Cha
p
ter Six: Remote O
p
eration
94
Digital Input Functions
(Continued)
Digital
Input No.
I/O Pin No. State Digital Input Function
916Low
High
Selects set point A
No function
10 15 Low
High
Selects set point B
No function
11 14 Low
High
Selects set point C
No function
12 13 Low
High
Selects set point D
No function
13 12 Low
High
Selects set point E
No function
14 11 Low
High
Selects analog set point
No function
15 10 Low
High
F.S. analog set point yields 1/10 the F.S.
pressure of the controlling transducer or 10%
position
F.S. analog set point yields F.S. pressure of
the controlling transducer or 100% position
(Pressure/position function controlled by
input 6)
16 9 Low
High
No function
No function
Table 17: Digital Input Functions
