Chapter Six: Remote Operation How To Select the Active Set Point
73
How To Select the Active Set Point
The 651 instrument provides five user-definable set points (set point A through set point E) and
one external analog set point, received through the I/O connector. The 651 controller uses the
“active” set point to control the system. Only one set point can be designated as the active set
point.
•
Issue the following command to select the active set point:
D
x
ENTER
where
x
= 1 for set point A
2 for set point B
3 for set point C
4 for set point D
5 for set point E
6 for the analog set point
