Rear Panel Cha

ter Three: Overview

Transducer Connector Pinout

Pin Number Function

1 +15V Supply

2 + Pressure input

3 Reserved

4 Reserved

5 Power ground

6 -15 V Supply

7 +15 V Supply

8 Reserved

9 -15 V Supply

10 Reserved

11 Digital ground

12 - Pressure input

13 Reserved

14 Reserved

15 Chassis ground

Table 11: Transducer Connector Pinout

System Interface Cables for MKS Transducers

Transducer Type Number Cable Numbers

122/124/223/225/622/623 CB112-2-10

127/128/624/625/626/627/628 CB259-5-10

120 CB120-1-10

220 CB112-10-10

121/221 CB112-14-10

Table 12: System Interface Cables for MKS Transducers
