MKS 651C - How to Set the Full Scale Level of the Analog Set Point

How To Adjust the Analog Set Point Value Cha
p
ter Six: Remote O
p
eration
78
How To Set the Full Scale Level of the Analog Set Point
1. Issue the following command to set the value of the analog set point:
S6
value
ENTER
where
value
= 0 for 100% of the controlling transducer’s range;
1 for 10% of the controlling transducer’s range.
2. To check the full scale level of the analog set point value, issue the request:
R0
ENTER
The 651 controller responds with the following message:
S0
value
where
value
is % of the controlling transducer’s range.
