RS-232 Communications
The 651 controller is initially configured with a baud rate of 9600, no parity, 8 data bits, and
CRLF delimiter. Follow the steps below to change any of the RS-232 communication
parameters.
1. From the
control mode
display, scroll to the next topic in the Setup menu.
BAUD RATE: 9600
2. Select the desired baud rate. The display list includes the following baud rate settings:
300
1200
2400
4800
9600*
* initial setting
3. Scroll to the next topic.
PARITY: NONE
4. Choose either
none
(8 data bits, no parity) or
even
(7 data bits, even parity) and scroll to
the next topic. The initial setting is 8 data bits, no parity.
DELIMITER: CRLF
5. Choose either CRLF (carriage return/line feed), or CR (carriage return). The initial
delimiter is CRLF.
