Chapter Four: System Setup Setu
Menu
45
Analog Set Point
1. From the
sensor type
display, scroll to the next topic in the Setup menu.
ANALOG SETPT RANGE:
10 VOLTS
2. Choose either 5 Volts or 10 Volts full scale signal.
The initial setting is 0 to 5 Volts. Refer to
How To View and Adjust the Analog Set
Point
, page 56, or
How To Adjust the Analog Set Point Value
,page 76, for more
information.
Valve Position Output
1. From the
analog setpt range
display, scroll to the next topic in the Setup menu.
VALVE SIGNAL OUTPUT:
10 VOLTS
2. Choose either 5 Volts or 10 Volts full scale for valve position output. The 651 controller
is initially configured for 0 to 10 Volts.
