Setup Menu Cha
ter Four: S
stem Setu
44
4. Scroll to the next topic.
PRESSURE UNITS:
Torr
5. Scroll through the display list until the unit of measure that the sensor has been calibrated
to, appears. The display list includes the following pressure units:
Torr* kPa
mTorr Pa
mbar cmH
2
O
µbar inH
2
O
* initial setting
6. Scroll to the next topic.
SENSOR SIGNAL:
10 VOLTS
7. Scroll through the display list until the sensor full scale voltage appears. The display list
includes the following selections:
1 Volt
5 Volts
10 Volts*
* initial value
8. Scroll to the next topic.
SENSOR TYPE:
ABSOLUTE
9. Choose either
absolute
or
differential
.
