Initial Settings
(Continued)
Parameter Default Options Page
Display Units Torr
mTorr, mbar,
µ
bar, Pa, kPa,
cmH
2
O, inH
2
O
44
Analog Set point Input 0 to 5 V 0 to 10 V 45
Pressure Sensor Input 0 to 10 V 0 to 5 V, 0 to 1 V 44
Analog Output Pressure: 0 to 10 V
Position: 0 to 10 V
No option
0 to 5 V
45
Control Mode Direct Acting Reverse 86
RS-232
Baud Rate
Parity/Data Bits
Delimiter
9600
None/8
CRLF
4800, 2400, 1200, 300
Even/7
CR
42
120
Battery Backup Failsafe
Mode
None Close valve, Open valve,
Disable
101
Table 25: Initial Settings
