Command Reference A
endix F: Command and Re
uest Reference
130
RS-232 Command Summary
(Continued)
Command Function
I1
value
Set softstart rate of set point A,
value
is % of full speed
I2
value
Set softstart rate of set point B,
value
is % of full speed
I3
value
Set softstart rate of set point C,
value
is % of full speed
I4
value
Set softstart rate of set point D,
value
is % of full speed
I5
value
Set softstart rate of set point E,
value
is % of full speed
I6
value
Set softstart rate of analog set point,
value
is % of full
speed
I7
value
Set softstart rate of open valve,
value
is % of full speed
I8
value
Set softstart rate of close valve,
value
is % of full speed
P1
value
Set low threshold for process limit 1
value
is % of F.S.
P2
value
Set high threshold for process limit 1
value
is % of F.S.
P3
value
Set low threshold for process limit 2
value
is % of F.S.
P4
value
Set high threshold for process limit 2
value
is % of F.S.
Z1
Zero the sensor
Z2
value
Special zero
value
is % F.S. of the base pressure reading
Z3
Remove the zero correction factors
Z4
Learn the zero of the analog set point. Assigns current
value of external analog set point to zero value. If the
current value of the analog set point is beyond
±
15% of
full scale, the controller ignores the command and does not
change the current zero value.
Table 26: RS-232 Command Summary
(Continued on next page)
