MKS 651C - Page 146

Command Reference A
pp
endix F: Command and Re
q
uest Reference
132
RS-232 Command Summary
(Continued)
Command Function
T5
value
Set point E type where
value
is:
0 = position
1 = pressure
T6
value
Set point analog type where
value
is:
0 = position
1 = pressure
B
value
Valve position output range where
value
is:
0 = 5 Volts
1 = 10 Volts
N
value
Direct/reverse control where
value
is:
0 = direct
1 = reverse
U
value
Sensor type where
value
is:
0 = Absolute
1 = Differential
X1
value
Set lead of set point A, where
value
= seconds
X2
value
Set lead of set point B, where
value
= seconds
X3
value
Set lead of set point C, where
value
= seconds
X4
value
Set lead of set point D, where
value
= seconds
X5
value
Set lead of set point E, where
value
= seconds
M1
value
Set gain of set point A, where
value
= % gain
M2
value
Set gain of set point B, where
value
= % gain
M3
value
Set gain of set point C, where
value
= % gain
M4
value
Set gain of set point D, where
value
= % gain
M5
value
Set gain of set point E, where
value
= % gain
V0
Select Self-Tuning control
V1
Select PID control
Table 26: RS-232 Command Summary
(Continued on next page)
