Motorola APX 7000 Basic Service Manual

Exploded Views and Parts Lists: APX 7000 Dual Display Exploded View Parts List Sec 1: 10-3
10.2 APX 7000 Dual Display Exploded View Parts
List
NOTE:
1. HIGH IMPACT GREEN and PUBLIC SAFETY YELLOW Colored Housings can be serviced in
the depot and can be ordered via AAD.
2. See
Table 10-2."Compatibility Table” on page 1:10-6.
Item
No.
Motorola Part
Number
Description
1 NHN7000_
01009304007
1
01009304008
1
Assy, Front Housing, Dual Display (Black)
Assy, Front Housing, Dual Display (Yellow)
Assy, Front Housing, Dual Display (Green)
2 3375622B01 Label, Housing, Dataside
3 01009304001 Assy, Main, Chassis
4 3275002C02 Seal, Membrane, Microphone
5 3275033C01 O-ring, Antenna, Main
6 3971892H01 Contact, Chassis Ground
7 7505316J16 Pad, Coin Cell Battery
8 7575218H01 Pad (x2), Thermal, Exp & VOCON Board
9
1375044C02
2
Assy, Control Top
10 3275031C01 Seal, Control Cap
11 1371891H02 Bezel, Control Top, Subassembly
12 3675581B01 Knob, Volume
13 3675590B03 Knob, Frequency
14 4575585B01 Lever, Secure
15 3275377H01 Seal, Cap, Torque Adder
16 0405659W01 Washer, Wave, Volume
17 0275361H01 Nut, Spanner, Volume
18 0400129O54 Washer, Lock, Antenna
19 0275891B01 Nut, Spanner, Antenna
20
NHN7017_
2
Assy, Back Chassis, Dual Display
21 3271816H01 Seal, Speaker, Dataside
22 6175619B02 Lens,Color Display
23 NHN7002_ Module, Speaker
24 3275002C02 Seal, Membrane, Microphone
25 3271819H01 Seal, Port
26 5475160H01 Label, Seal, Port
27 01009304004
01009304005
01009304006
Assy, Grille, Speaker (Black)
Assy, Grille, Speaker (Yellow)
Assy, Grille, Speaker (Green)
28 0375962B01 Screw (x2), M2.5 X 0.45, 30.10 LG
29 0375962B02 Screw (x2), M2.5 X 0.45, 24.45 LG
30 0375962B03 Screw (x2), M2.5 X 0.45, 9.2 LG
31 0375962B04 Screw (x2), M2.5 X 0.45, 7.0 LG
32 32009064001 Plug, Support, Connector
33 3275882B01 Door, Seal, Memory
34 3875126H01 Cap, Chassis Boss, Universal Connector
35
01009304019
2
Display, Color, Back
36
MNCN6202_
2
Assy, VOCON Board, Dual Display
37 6003710K08 Battery, Backup, Coincell
38 MNUR4001_
MNUS4000_
MNUT4000_
MNUS4002_
MNUT4004_
Assy, Board, RF (VHF / 700–800 MHz)
Assy, Board, RF (UHF1 / 700–800 MHz)
Assy, Board, RF (UHF1 / VHF)
Assy, Board, RF (UHF2 / 7/800 MHz)
Assy, Board, RF (UHF2 / VHF)
39 3275623B02 Pad, Thermal, Outer
40 75009299001 Pad, Thermal, Inner
41 3271829H01 Seal, Connector, Battery
42 MHLN6977_ Assy, Board, Expansion
43 1575250H01 Cover, Connector, Universal Conncector
44 3371896H01
3371896H02
Label, Grille, Speaker for APX 7000 radios
Label, Grille, Speaker for APX 7000R radios
50 33009274001 Label, Main Housing FM, Dual Displays
Item
No.
Motorola Part
Number
Description

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
