ASTRO APX 7000 700–800 MHz and UHF1 Model Chart Sec 1: xi
ASTRO APX 7000 700–800 MHz and UHF1 Model Chart
MODEL NUMBER:
FCC ID:
H97TGD9PW1_N
AZ489FT7040
MODEL DESCRIPTION: 700–800 / UHF1, APX 7000
Top Display Model
Dual Display Model
ITEM NUMBER DESCRIPTION
XX01009304001 Sub-Assembly, Main Chassis
X 01009304019 Display, Color
XX01009304004 Grille, Speaker
XX0375962B01 Screw, Chassis (M2.5 x 0.45 x 31mm)
XX0375962B02 Screw, Chassis (M2.5 x 0.45 x 25mm)
XX0375962B03 Screw, Chassis (M2.5 x 0.45 x 7.3mm)
XX1110027B23 Grease, Fluorocarbon Lubricant
XX1375044C02 Assembly, Control Top
XX1575250H01 Cover, Universal Connector
X 1575356H01 Cover, Belt Clip, Top Display
XX32009064001 Plug, Controls Flex Support
XX3271829H01 Seal, Battery Connector
XX3275623B02 Pad, Thermal, Outer
XX3275882B01 Seal, Memory Card Portal
XX3371896H01 Label, Grille Top APX 7000
X 3385836D09 Label, Blank, Top Display
XX3875126H01 Cap, Chassis Screw Boss
XX75009299001 Pad, Thermal, Inner
XX7575218H01 Pad, Thermal, Expansion / VOCON
XXMHLN6977_ Assembly, Expansion Board
X MNCN6202_ Assembly, VOCON Board, Dual Display
X MNCN6203_ Assembly, VOCON Board, Top Display
X NHN7000_ Assembly, Main Housing, Dual Display
X NHN7001_ Assembly, Main Housing, Top Display
XXNHN7002_ Assembly, Speaker Module
X NHN7017_ Sub-Assembly, Back Chassis, Dual Display
X NHN7004_ Sub-Assembly, Back Chassis, Top Display
XXMNUS4000_ Assembly, RF Board
XXNNTN8160_ Bluetooth Upgrade Kit
XXPMLN5335_ User Guide CD, APX 7000
Note:
X =Item Included.
Refer Appendix A for antennas, batteries and other applicable accessories.
