Sec 2: 8-4 Disassembly/Reassembly Procedures: Required Tools and Supplies
8.2 Required Tools and Supplies
8.3 Fastener Torque Chart
Tab l e 8 -3 lists the various fasteners by part number and description, followed by the torque values
and the location where used. Torque all fasteners to the recommended value when assembling the
radio.
Table 8-2. Required Tools and Supplies
Tools
Motorola
Part Number
Supplier
Supplier
Part Number
Remarks
Bit, Torx IP8 – – – Torx T8 may be used, but Torx Plus IP8 is
recommended
Bit, Antenna
Spanner
66009258001 Motorola –
Black Stick – Hexacon
Electric Co.
MA-800G
Seater,
Secure Lever
66009261001 Motorola –
Driver,
Tor q u e
–––
Vacuum
Pump Kit
NLN9839_ Motorola – For Vacuum Test
Grille
Eliminator
66009275001 Motorola – For Vacuum Test and Pressure Test
Vacuum
Adapter
66009259001 Motorola – For Vacuum Test and Pressure Test
Pressure
Pump Kit
NTN4265_ Motorola – For Pressure Test
Table 8-3. Required Tools and Supplies
Motorola
Part Number
Description Repair Torque (in-lbs)
0275891B01 Antenna Spanner Nut (16) 16
0375962B01 Top Screw (23) 10
0375962B02 Center Screw (24) 10
0375962B03 Bottom Screw (25) 10
3009357001 Control Top Screw (26) 7
