Motorola APX 7000 Basic Service Manual

Sec 2: xii ASTRO APX 7000XE 700–800 MHz and UHF2 Model Chart
ASTRO APX 7000XE 700–800 MHz and UHF2 Model Chart
MODEL NUMBER:
FCC ID:
H49TGD9PW1_N
AZ489FT7042
MODEL DESCRIPTION: 700–800 / UHF2, APX 7000XE
Black Model
Impact Green Model
Safety Yellow Model
ITEM NUMBER DESCRIPTION
XXX 1009304001 Sub-Assembly, Main Chassis
X NHN7051 Grille, Speaker, Kit_Black
X NHN7053 Grille, Speaker, Kit_Impact Green
X NHN7052 Grille, Speaker, Kit_Safety Yellow
X NHN7048 Control Top, Black
X NHN7049 Control Top, Impact Green
X NHN7050 Control Top, Safety Yellow
X 15009584001 Housing, Assembly Black
X 15009584003 Housing, Assembly Impact Green
X 15009584002 Housing, Assembly Safety Yellow
XXX 0375962B01 Screw, Chassis (M2.5 x 0.45 x 31mm)
XXX 0375962B02 Screw, Chassis (M2.5 x 0.45 x 25mm)
XXX 0375962B03 Screw, Chassis (M2.5 x 0.45 x 7.3mm)
XXX 0275891B01 Spanner, Nut
XXX 3009357001 Screw, Control Top (M2.5 x 0.45 x 18 )
XXX 400129054 Washer, Star
XXX 1110027B23 Grease, Fluorocarbon Lubricant
XXX 1575250H01 Cover, Universal Connector
XXX 1575356H01 Cover, Belt Clip, Top Display
XXX 32009064001 Plug, Controls Flex Support
XXX 3271829H01 Seal, Battery Connector
XXX 3275623B02 Pad, Thermal, Ring, Outer
XXX 3275882B01 Seal, Memory Card Portal
3385836D09 Label, Blank, Top Display
3385836D10 Label, FM, Top Display
XXX 3875126H01 Cap, Chassis Screw Boss
XXX 75009299001 Pad, Thermal, RF, PA Inner (16.7 x 3.7mm)
XXX 7575218H01 Pad, Thermal Expansion/VOCON
XXX MHLN6977_ Assembly, Expansion Board
XXX MNCN6203_ Assembly, VOCON Board, Top Display
XXX 15009584001_ Assembly, Main Housing_Black
XXX NHN7002_ Assembly, Speaker Module
XXX NHN7004_ Sub-Assembly, Back Chassis, Top Display
XXX MNUS4002_ Assembly, RF Board
XXX 38009295001 Grip, Insert
XXX 36009258001 Knob, Frequncy
XXX 36009257001 Knob, Volume
NNTN8160_ Bluetooth Upgrade Kit
XXX PMLN5335_ User Guide CD, APX 7000/APX 7000XE
Note:
X =Item Included.
• Refer Appendix A for antennas, batteries and other applicable accessories.

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
