Motorola APX 7000 Basic Service Manual

Disassembly/Reassembly Procedures: Antenna Sec 2: 8-5
8.4 Antenna
This section explains how to attach and remove the antenna.
8.4.1 Attach Antenna
To attach the antenna:
With the radio turned off, turn the antenna clockwise to attach it to the radio.
Figure 8-2. Attaching the Antenna
8.4.2 Remove Antenna
To remove the antenna:
With the radio turned off, turn the antenna counter-clockwise to remove it from the radio.
Figure 8-3. Removing the Antenna

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
