Motorola APX 7000 Basic Service Manual

Sec 1: 10-6 Exploded Views and Parts Lists: APX 7000 Top Display Exploded View Parts List
Table 10-2. Compatibility Table
Compatibility Table
Assy, Control Top – 1375044C02 Assy, Control Top – 1375044C01 Display, Color, Black – 01009304019 Display, Color, Black – 01009304003 Assy, Back Chassis – Dual Display, NHN7017_ Assy, Back Chassis – Dual Display, NHN7003_ VOCON Board, Top – Display MNCN6203_ VOCON Board, Top – Display MNCN6201_ VOCON Board, Dual – Display MNCN6202_ VOCON Board, Dual – Display MNCN6200_
Assy, Control Top – 1375044C02
––●●●●●●●●
Assy, Control Top –1375044C01
––●●●●●●●●
Display, Color, Black – 01009304019
●●––● x ––● x
Display, Color, Black – 01009304003
●●––x ● ––x ●
Assy, Back Chassis – Dual Display, NHN7017_
●●●x ––––● x
Assy, Back Chassis – Dual Display, NHN7003_
●●x ● ––––x ●
VOCON Board, Top – Display MNCN6203_
●●––––––––
VOCON Board, Top – Display MNCN6201_
●●––––––––
VOCON Board, Dual – Display MNCN6202_
●●●x ● x ––––
VOCON Board, Dual – Display MNCN6200_
●●x ● x ● ––––
Note:
● Compatible
x Not Compatible
– Not Applicable

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
