Motorola APX 7000 Basic Service Manual

Disassembly/Reassembly Procedures: Required Tools and Supplies Sec 1: 8-5
8.2 Required Tools and Supplies
8.3 Fastener Torque Chart
Tab l e 8 -3 lists the various fasteners by part number and description, followed by the torque values
and the location where used. Torque all fasteners to the recommended value when assembling the
radio.
Table 8-2. Required Tools and Supplies
Tools
Motorola
Part Number
Supplier
Supplier
Part Number
Remarks
Bit, Torx IP8 – – – Torx T8 may be used, but Torx Plus IP8 is
recommended
Bit, Volume
Spanner Nut
66009256001 Motorola –
Bit, Antenna
Spanner
66009258001 Motorola –
Black Stick – Hexacon
Electric Co.
MA-800G
Seater,
Secure Lever
66009261001 Motorola –
Driver,
Torque
–––
Vacuum
Pump Kit
NLN9839_ Motorola – For Vacuum Test
Grille
Eliminator
66009255001 Motorola – For Vacuum Test and Pressure Test
Vacuum
Adapter
66009259001 Motorola – For Vacuum Test and Pressure Test
Pressure
Pump Kit
NTN4265_ Motorola – For Pressure Test
Table 8-3. Required Tools and Supplies
Motorola
Part Number
Description Repair Torque (in-lbs)
0275361H01 Volume Spanner Nut (17) 8
0275891B01 Antenna Spanner Nut (19) 16
0375962B01 Top Screw (28) 10
0375962B02 Center Screw (29) 10
0375962B03 Bottom Screw (30) 10
0375962B04 Control Top Screw (31) 8

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
