Sec 1: 4-2 Recommended Test Equipment and Service Aids: Service Aids
4.2 Service Aids
Refer to Table 4-2 for a listing and description of the service aids designed specifically for servicing
this family of radios. These kits and/or parts are available from the Radio Products and Solutions
Organization offices listed in “Appendix B. Replacement Parts Ordering” on page B-1. While all of
these items are available from Motorola, most are standard shop equipment items, and any
equivalent item capable of the same performance may be substituted for the item listed.
Table 4-2. Service Aids
Motorola Part
Number
Description Application
1110027B23 Speaker Module Seal
Lubricant
Used to ensure good sealing of the Speaker Module to the
Main Chassis.
5880384G68 SMA to BNC Adapter Adapts radio’s antenna port to BNC cabling of test equipment.
66009254001 APX 7000/ APX 7000XE
Battery Adapter
Used in place of battery to connect radio to an external power
supply. Requires RLN4510_.
66009255001 Grille Eliminator Special tool used when pressure testing the radio. Replaces
the radio grille to seal the port vent.
66009256001 Volume Potentiometer Outer
Spanner Bit
Used to assemble and disassemble the spanner nut on the
volume potentiometer.
66009258001 Antenna Spanner Bit Used to assemble and disassemble the spanner nut on the
antenna bushing.
66009259001 Vacuum Adapter Submersible radios only. Connects the vacuum/pressure hose
to the radio.
66009260001
66009260003
Board Analysis Fixture
(APX 7000)
Board Analysis Fixture
(APX 7000XE and
future APX 7000)
Special fixture that allows radio’s internal board to be mounted
externally. Provides easy access to electronic circuits,
required for board-level troubleshooting.
NOTE: Contact Motorola Solutions Radio Products and
Solutions Organization (1-800-927-2744) to
determine which version of fixture is required for
your APX 7000 radio.
NLN9839_ Vacuum Pump Kit Submersible radios only. Vacuum pump with gauge and
vacuum hose. Requires 66009259001 Adapter Kit.
NTN4265_ Pressure Pump Kit Submersible radios only. Pressure pump with gauge and
pressure hose. Requires 66009259001 Adapter Kit.
DVN4233_ Customer Programming
Software (CPS) and Tuner
Software
CPS allows customer-specific programming of modes and
features. Tuner software required to perform alignment of
radio parameters.
PMKN4012_ Programming Cable Used to program the radio through Customer
Programming Software and Tuner Software.
PMKN4013_ Programming/Service Cable Used to program and service the radio through Customer
Programming Software and Tuner Software.
RLN4510_ 7.5 Volt Universal Battery
Eliminator
Used in conjunction with the 66009254001 to adjust the
supply voltage to 7.5 Vdc. Allows a multimeter to be attached
for monitoring and adjusting voltage and current levels.
