Motorola APX 7000 Basic Service Manual

Performance Checks: Display Radio Test Mode (Dual-Display Version) Sec 1: 5-3
5.2 Display Radio Test Mode (Dual-Display Version)
This section provides instructions for performing tests in display radio test mode.
5.2.1 Access the Test Mode
To enter the display radio test mode:
1. Turn the radio on.
2. Within 10 seconds after “SELF TEST” is complete, press Side Button 2 five times in
succession.
The radio shows a series of displays that give information regarding various version numbers
and subscriber specific information. The displays are described in Table 5-2.
Table 5-2. Test-Mode Displays
Name of Display Description Appears
Service The literal string indicates the radio has
entered test mode.
Always
Host version The version of host firmware is displayed. Always
DSP version The version of DSP firmware is displayed. Always
Secure version Version of the encryption software When the radio is secure
equipped
KGI algorithms name
(Encryption Type 1)
Type of encryption being used When the radio is secure
equipped
KG2 algorithms name
(Encryption Type 2)
Type of encryption being used When the radio is secure
equipped and 2 or more
algorithms are loaded
KG3 algorithms name
(Encryption Type 3)
Type of encryption being used When the radio is secure
equipped and 3 or more
algorithms are loaded
KG4 algorithms name
(Encryption Type 4)
Type of encryption being used When the radio is secure
equipped and 4 or more
algorithms are loaded
KG5 algorithms name
(Encryption Type 5)
Type of encryption being used When the radio is secure
equipped and 5 or more
algorithms are loaded
Model number The radio’s model number, as
programmed in the codeplug
Always
Serial number The radio’s serial number, as programmed
in the codeplug
Always
ESN The radio’s unique electronic serial
number
Always
ROM Size The memory capacity of the host FLASH
part
Always
