Motorola APX 7000 Basic Service Manual

Exploded Views and Parts Lists: APX 7000XE Exploded View Parts List Sec 2: 10-3
10.2 APX 7000XE Exploded View Parts List
Item
No.
Motorola Part
Number
Description
1 15009584001
15009584003
15009584002
Housing, Assembly Black
Housing, Assembly Impact Green
Housing, Assembly Safety Yellow
2 3385836D09
3385836D10
Label, Blank, Top Display
Label, FM, Top Display (where applicable)
3 38009295001 Grip, Rubber, Insert
4 01009304001 Assy, Main, Chassis
5 3275002C02 Seal, Membrane, Microphone
6 3275033C01 O-ring, Antenna Main
7 39711892H01 Contact, Chassis Ground
8 7505316J16 Pad, Coin Cell Battery
9 7575218H01 Pad (x2), Thermal, Exp & VOCON Board
10 N H N 7 0 4 8 _
N H N 7 0 4 9 _
NHN7050_
Control Top, Black
Control Top, Impact Green
Control Top, Safety Yellow
11 33009276001 Label, Control Top (x2)
12 36009258001 Knob, Volume
13 36009258001 Knob, Frequency
14 3275377H01 Seal, Control Top
15 0400129054 Washer, Lock Antenna
16 0275891B01 Nut, Spanner, Antenna
17 NHN7004_ Sub-Assembly, Back Chassis, Top Display
18 NHN7002_ Module, Speaker
19 3275002C02 Seal, Membrane, Microphone
20 3271819H01 Seal, Port
21 5475160H01 Label, Seal, Port
22 N H N 7 0 5 1 _
NHN7053_
NHN7052_
Grille, Speaker Kit_Black
Grille, Speaker Kit_Impact Green
Grille, Speaker Kit_Safety Yellow
23 0375962B01 Screw (x2) M2.5 x 0.45, 30.10 LG
24 0375962B02 Screw (x2) M2.5 x 0.45, 24.45 LG
25 0375962B03 Screw (x2) M2.5 x 0.45, 9.2 LG
26 3009357001 Screw, Control Top (M2.5 x 0.45 x 18 )
27 32009064001 Plug, Support, Connector
28 3275882B01 Door, Seal, Memory
29 3875126H01 Cap, Chassis Boss, Universal Connector
30 MNCN6203_ Assy, VOCON Board, Dual Display
31 6003710K08 Battery, Backup, Coincell
32 MNUR4001_
MNUS4000_
MNUT4000_
MNUS4002_
MNUT4004_
Assembly, RF Board (7–800/VHF)
Assembly, RF Board (7–800/UHF1)
Assembly, RF Board (UHF1/VHF)
Assembly, RF Board (7–800/UHF2)
Assembly, RF Board (UHF2/VHF)
33 3275623B02 Pad, Thermal, Outer
34 75009299001 Pad, Thermal, Inner
35 3271829H01 Seal, Connector, Battery
36 MHLN6977_ Assy, Board, Expansion
37 NNTN8160_ Bluetooth Upgrade Kit (where applicable)
38 1575250H01 Cover, Connector, Universal Connector
39 1575356H01 Cover, Clip, Belt
Item
No.
Motorola Part
Number
Description

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
