Motorola DS9208 Product Reference Guide

Symbologies 10 - 87
GS1 Data Matrix
Parameter # 1336
To enable or disable GS1 Data Matrix, scan the appropriate bar code below.
Maxicode
Parameter # 294
To enable or disable Maxicode, scan the appropriate bar code below.
Enable GS1 Data Matrix
(1)
*Disable GS1 Data Matrix
(0)
Enable Maxicode
(1)
*Disable Maxicode
(0)

Motorola DS9208 Specifications

General

Drop Specification	Withstands multiple 5 ft./1.5 m drops to concrete
Scanning Technology	Imager
Tilt Angle	± 65°
Skew Angle	± 60°
Connectivity	USB, RS232, Keyboard Wedge
Decode Capability	1D, 2D and PDF417
Light Source	650nm visible laser diode
Operating Temperature	32° to 104° F/0° to 40° C
Print Contrast	25% minimum reflectance
Pitch Angle	60°
Storage Temperature	-40° to 158° F (-40° to 70° C)
Humidity	5% to 95% relative humidity, non-condensing
Electrical Safety	UL
EMC	FCC Part 15 Class B
Cable Length	6 ft (1.8m)
Power Consumption	2.5 Watts (500mA @ 5V)
Scan Pattern	Omnidirectional
