Motorola DS9208 Product Reference Guide

A - 10 DS9208 Product Reference Guide
2D Symbologies
PDF417
15 Enable 10-84
MicroPDF417
227 Disable 10-84
Code 128 Emulation
123 Disable 10-85
Data Matrix
292 Enable 10-86
Data Matrix Inverse
588 Inverse Autodetect 10-86
GS1 Data Matrix 1336 Disable 10-87
Maxicode
294 Disable 10-87
QR Code
293 Enable 10-88
QR Inverse
587 Regular 10-88
GS1 QR 1343 Disable 10-89
MicroQR
573 Enable 10-89
Aztec
574 Enable 10-90
Aztec Inverse
589 Inverse Autodetect 10-90
Han Xin 1167 Disable 10-91
Han Xin Inverse 1168 Regular 10-91
Symbology-Specific Security Levels
Redundancy Level
78 1 10-92
Security Level (UPC/EAN and Code 93) 77 1 10-94
1D Quiet Zone Level 1288 1 10-95
Intercharacter Gap Size
381 Normal 10-96
Macro PDF
Flush Macro PDF Buffer
N/A N/A 10-97
Abort Macro PDF Entry
N/A N/A 10-97
DL Parsing Parameters
Driver’s License Parsing N/A No Driver’s License Parsing 13-2
Driver’s License Parse Field Bar Codes N/A N/A 13-4
AAMVA Parse Field Bar Codes N/A N/A 13-7
Set Default Parameter N/A N/A 13-17
Output Gender as M or F N/A N/A 13-17
Table A-1 Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.

Motorola DS9208 Specifications

General

Drop Specification	Withstands multiple 5 ft./1.5 m drops to concrete
Scanning Technology	Imager
Tilt Angle	± 65°
Skew Angle	± 60°
Connectivity	USB, RS232, Keyboard Wedge
Decode Capability	1D, 2D and PDF417
Light Source	650nm visible laser diode
Operating Temperature	32° to 104° F/0° to 40° C
Print Contrast	25% minimum reflectance
Pitch Angle	60°
Storage Temperature	-40° to 158° F (-40° to 70° C)
Humidity	5% to 95% relative humidity, non-condensing
Electrical Safety	UL
EMC	FCC Part 15 Class B
Cable Length	6 ft (1.8m)
Power Consumption	2.5 Watts (500mA @ 5V)
Scan Pattern	Omnidirectional
