3 - 6 DS9208 Product Reference Guide
Typical Working Distance See
Decode Ranges on page 2-8
.
Imaging Characteristics
Graphics Format Support Images can be exported as bitmap, JPEG, or TIFF
Image Transfer Speed USB 2.0: Up to 12 megabits/second
RS-232: Up to 115 kb/second
Image Transfer Time Typical USB application is ~0.2 seconds with a compressed JPEG of 100kb
Image Quality 120 PPI on a 4 x 6 in (10.2 x 15.2 cm) document @ 4.7 in (11.9 cm)
Interfaces Supported
USB, RS-232, RS-485 (IBM 46xx protocols), keyboard wedge
User Environment
Operating Temperature 32º F to 104º F (0º C to 40º C)
Humidity 5% to 85% RH, non-condensing
Drop Specifications Withstands multiple 5 ft. (1.5 m) drops to concrete
Sealing IP52
Ambient Light Immunity Immune to natural and artificial ambient light (i.e., sunlight, incandescent,
fluorescent, mercury vapor, sodium vapor)
Options
Electronic Article Surveillance
(EAS)
Compatible with Checkpoint EAS deactivation systems
Mounting Options Wall mount bracket, locking mount bracket
Table 3-2
Technical Specifications (Continued)
