9. Troubleshooting
Extraction chamber fault
This chapter describes the approach to fault analysis and troubleshooting the extraction chamber. The
subsequent brief instructions describe the process in short form. The following chapters describe the
extraction chamber process with detailed background information on the brief instructions.
9.1.1 Brief instructions on site
Execute the following points in succession:
• NEVER switch the power supply of a faulty device on and off to make it work again!
• Please ensure that the “Activate device” key is active ( ).
• Please ensure that the external slide / ball valve has not been accidentally closed.
• Check the fault status display on the main menu.
• Use the MSENSE® DGA Service Tool to read out the service data.
• Carefully remove the device's protective hood.
• Check the extraction chamber by way of visual inspection.
• Check to see if oil is found in the hood or on the device's components.
• Check if loose pneumatic connections (air white / oil yellow) can be found.
• Check for loose electrical connections.
• If necessary, repair or replace the defective components.
• If there are no faults in the device, open the Extraction Status menu.
• Acknowledge the fault in the extraction status menu using the key.
• Monitor the device while the initialisation cycle is in progress.
• Wait for the next measurement cycle and monitor the process.
• Should a fault occur again in the device, read out the service data once again.
• Send the read out service data (ZIP file) to the MR service e-mail specified on page 2 and await
a response.
9.1.2 Brief instructions by way of remote diagnosis
Execute the following points in succession:
• NEVER switch the power supply of a faulty device on and off to make it work again!
• Use the MSENSE® DGA Service Tool to read out the service data.
• Send the read out service data (ZIP file) to the MR service e-mail specified on page 2 and await
a response.
• Should the MR Service Department identify the problem as a hardware fault, an on-site service
call is required.
• The MR Service Department sends a command file which resets the device.
• Use the MSENSE® DGA Service Tool to transfer this command file to the device.
• NEVER load an old command file, which you obtained earlier for another device, onto the
current device.
• Check the operating status after a short period.
• If the device does not work, an on-site service is required.
