6.6.1 Graph view
After selecting the measurement variable to be displayed, its graphic time history is displayed.
The following functions are available in the time line display:
Scroll to the right on the time line (future)
Scroll to the left on the time line (past)
Expand presentation. The smallest resolution is 3 days / page
Zoom out. The largest resolution is 8 hours / page
Switch to tabular display
Exit menu
