o There is a date entry: There was an alarm in the past for this measurement variable, which was
confirmed at the time shown.
o There is no date entry: There was no alarm for this measurement variable in the past.
• Symbol - One-level threshold limit breach active: The defined threshold value “Threshold 1”
is currently exceeded. The threshold value was breached at the point in time shown.
• Symbol - One-level threshold limit breach inactive: The defined threshold value “Threshold
1” was exceeded in the past. The threshold value “Threshold 1” was breached again at the point in
time shown.
• Two-level threshold limit breach active:
o Symbol: The defined threshold values “Threshold 1” and “Threshold 2” are currently ex-
ceeded. The threshold value “Threshold 2” was breached at the point in time shown.
o Symbol: The defined threshold values “Threshold 1” and “Threshold 2” were exceeded in
the past. The threshold value “Threshold 2” was again undershot at the time shown, but is still
above the threshold value “Threshold 1”.
• Symbol - Two-level threshold limit breach inactive: The defined threshold values “Thresh-
old 1” and “Threshold 2” were exceeded in the past. The threshold value “Threshold 1” was
breached again at the point in time shown.
The following functions are available in the “Alarm / Alarm history” menu:
To Next Page
