2.6 Optional Printer
The Printer can print calibration and bump result receipts and calibrations stickers for gas detec-
tors [
Fig. 7]. The Receipt/ Sticker Printer uses a USB cable to connect to the port of the farthest
right Test Stand [ Fig. 3].
Labels are available in two formats [ chapter 7.2]:
- Format #1: Calibration Sticker only (2 cm x 2 cm square label).
- Format #2; Receipt and Sticker combined.
Fig. 8 Optional Printer
2.7 Optional Multi-Unit Charger
There are two configurations of the optional Multi-Unit Charger (MUC). The ALTAIR 4/4X MUC
can simultaneously charge up to four ALTAIR 4/4X gas detectors. Similarly the ALTAIR 5/5X MUC
can charge four 5/5X gas detectors. Each Multi-Unit Charger contains its own power supply and
does not connect electrically to the Test Stand. The housing is designed to physically connect to
each other, whether bench-top or wall-mounted (if desired).
The light indicators on the Multi-Unit Charger are defined as follows:
- Red indicates that the unit is charging
- Green indicates that the unit is fully charged or no unit is inserted.
There can be as much as a 10 minute window between when the instrument battery indicator
shows charged and the Multi-Unit charger status indicator changes. The instrument indicator is
the most accurate and will indicate the true charge state of the battery.
Verify the Multi-Unit Charger indicator lights red when an instrument is inserted. A fully
charged instrument will momentarily flash red and the indicator will light green. If the red
light does not engage the instrument may not be seated properly on the charging prong.
Instruments whose battery is completely discharged will be need to trickle-charge
prior to normal charging operations. Such instruments will show a green LED during the
trickle-charge period until normal charging is initiated, at which time the red LED will be
active.
