6.5 Cylinder Data Does Not Display
If using an electronic Cylinder Holder with RFID-
tagged MSA gas cylinders, the general cylinder
parameters automatically populate. If using a non-electronic Cylinder Holder or test gas from an
independent source the user must manually enter cylinder data. Gas cylinder pressure will ONLY
display with an electronic Cylinder Holder.
Cylinder Data Does Not Display:
(1) If using an electronic Cylinder Holder, verify the pressure is displayed on the Home screen.
If not displayed, the Cylinder Holder and Test Stand may not be communicating via the con-
nector. Remove the flange screws and push the two stands together. If a valid pressure read-
ing displays re-insert the flange screws.
(2) If using an electronic Cylinder Holder, ensure the test gas cylinder is properly screwed into
the base.
(3) If not using an RFID-tagged gas cylinder, verify that cylinder parameters have been entered
[ GX2 Gas Setup].
(4) Using an independent regulator, ensure the test cylinder(s) contain test gas.
(5) If not using an electronic Cylinder Holder, ensure the cylinder description is entered in the
cylinder set up screens. Refer to the cylinder configuration set up section [ chapter 4.7] of
this manual.
6.6 Test Stand Yellow LED Blinking
The Test Stand provides a comprehensive status of hardware and firmware components through
the GX2 Status screen, accessed on the Administrator screen [ Fig. 23] by selecting the
GX2 Status button. The table below shows the information reported for each Test Stand and
Cylinder Holder in a bank. If one of these components is in Fault, a red message displays,
indicating the error.
The cylinder gauges on the Home screen and the subsequent cylinder screens only dis-
play pressure, Part Number, Lot Number, and Expiration fields if using an electronic
Cylinder Holder.
Cylinder Holder (number) If Status is Fail, then:
-Cylinder Gas Indicates a fault condition with the cylinder (expired or empty)
-Flash Memory Return to an Authorized MSA Service Center for repair
-RAM Memory Return to an Authorized MSA Service Center for repair
-Power Supply 12V Return to an Authorized MSA Service Center for repair
-Power Supply 6V If GX2 6V power supply shows failed, try reconnecting.
Otherwise, return to an Authorized MSA Service Center for repair
-RFID Tag Return to an Authorized MSA Service Center for repair
-Communications Return to an Authorized MSA Service Center for repair
- RFID Read Corrupt RFID tag. Enter cylinder information via manual setup
screens.
-Data Corrupt RFID tag. Enter cylinder information via manual setup
screens.
