Setting Up the GALAXY GX2
GALAXY GX2
39
US
(2) Enter the Static IP Address on the number keypad.
Z The yellow highlighted cursor then moves to the Subnet field.
(3) Enter the Subnet on the number keypad.
Z The yellow highlighted cursor then moves to the Gateway field.
(4) Enter the Gateway on the number keypad.
Z The yellow highlighted cursor then moves to the Subnet field.
(5) Select Save.
4.6 Instrument Configuration
The GALAXY GX2 Automated Test System allows the user to configure a limited set of gas de-
tector settings at the Test Stand, as defined below:
Gas Detector Settings Configurable at the Test Stand
The user can save those settings to a reusable file for later use [
The settings are stored on the Digital Secure USB (black) key. No instrument setting files are
stored locally.
The Instrument Configuration screens are accessed only when an instrument is inserted in the
Test Stand. To configure an instrument, insert the Digital Secure USB (black) key and navigate
to the Administrator page. Select GX2 Configuration screen [ Fig. 23] and then
Instrument Configuration. The Instrument Configuration screen displays.
- Time & Date (automatically set to the
Test Stand time & date)
- 24-Hour Time
- Cal Gas Value
- Company Name
- Company Department Name
- User Name
- Exposure Warning
- Exposure Alarm
- TWA
- STEL
- Deficiency Warning
- Deficiency Alarm
- Alarm Set-point
- Latching Enabled
- Vibration Motor On/Off
- LED On/Off
- Horn Enable
- Man Down (if applicable)
- Enable/Disable Sensor Channel
- Cal Due On/Off
- Cal Due Interval
- Average Enabled
- Peak Enabled
- Datalog Interval
All settings entered in Instrument Configuration must be saved on the respective
screens. To apply settings to the instrument, the user must select
Update Settings before removing the instrument.
