4
Mounting and installation
SIM card
14 30302710-02-EN V7.20141016
– In certain versions, you will also require the D-Sub <-> CPC connector cable, item no.
30322541
When there is more than one terminal in the tractor cab, you may need to change certain settings in
order to enable two-way communication. Find out more: Using two terminals [➙ 25]
1. Connect the 9-pin plug A of the basic vehicle harness to port A of the terminal.
2. Tighten the safety screws on the connector.
SIM card
The terminal must be equipped with a SIM card so that you can use the farmpilot portal. If you do not
intend to use the farmpilot portal, you will not need any SIM card.
You must purchase the SIM card from your mobile phone provider.
Select a mobile phone provider that can guarantee good mobile phone reception on your fields. A
good connection is required in order for work with the farmpilot portal to run smoothly.
The SIM card must meet the following requirements:
▪ It must be GPRS-capable.
▪ It must be PIN-free. Inform your mobile phone provider about this requirement before purchasing
the SIM card.
▪ The contract must enable data transfer.
Inserting the SIM card
Required tool
▪ Torx TX10 screwdriver
1. Switch off the terminal and disconnect all cable connections to other equipment.
2. Unscrew the SIM card cover on the reverse of the terminal. Use a Torx TX10 screwdriver.
3. Press latch release with finger nail.
Which SIM card?
