7
Configuring the terminal in the Service application
GPS receiver
36 30302710-02-EN V7.20141016
The driver of the ME Lightbar "LightBar" is deactivated. Otherwise the DGPS receiver cannot be
configured.
1. Switch to the "GPS" screen:
| Service |
⇨ The following screen appears:
2.
- Click on the desired parameter. First of all, set the "Correction signal" parameter.
⇨ A selection list will appear.
3.
- Select the desired value.
⇨ The
icon will appear next to the value.
4.
- Back
⇨ For some parameters is it necessary to restart the terminal. In these cases, the following
notification will appear:
"Restart the terminal."
⇨ You have configured the DGPS receiver.
5. Reconnect all of the additional devices that you had disconnected for the configuration.
Parameters for the GPS receiver
Baud rate
Only appears when the "Standard" driver is selected.
Setting for the speed at which the GPS receiver sends data to the terminal. The parameter sets the
baud rate for the terminal.
Satellite 1 and Satellite 2
Satellite 1 – primary DGPS satellite. The DGPS receiver will connect to this satellite in the first
instance.
Satellite 2 – secondary DGPS satellite. The DGPS receiver will only connect to this satellite in the
event that the primary satellite fails.
Your satellite selection will depend on which satellite currently has the best availability in your region.
Potential values:
▪ "Auto"
The software automatically selects the current best satellite. This setting is not recommended, as
it slows down the start-up of the DGPS receiver.
