Tractor-ECU application
Activating vehicle profiles
8
30302710-02-EN V7.20141016 65
The jobcomputer of the farm equipment in use is connected to the terminal
In the jobcomputer the geometry of the farm equipment is configured.
1. Measure the distance between the attachment point of the attached or trailed implement and the
GPS receiver.
2. Input the measured distance as parameter "Offset X".
3. Measure the distance between the longitudinal axis of the machine and the GPS receiver.
4. Input the measured distance as parameter "Offset Y".
To determine the distances for self-propelled machines with an ISOBUS job computer:
The jobcomputer of the farm equipment in use is connected to the terminal
In the jobcomputer the geometry of the farm equipment is configured.
1. Input 0 inch as parameter "Offset X".
2. Measure the distance between the longitudinal axis of the machine and the GPS receiver.
3. Input the measured distance as parameter "Offset Y".
Activating vehicle profiles
In order to work with the inserted parameters, you must activate the vehicle profile of the used
vehicle.
1. Call up the Tractor-ECU application.
| Tractor-ECU
2.
- Call up the list of vehicles.
3. Select the vehicle profile.
4.
- Activate the vehicle profile.
Procedure
8.3
Procedure
